Slitting Line

Hot Rolled Galvanized Slitting Machine Line for Stainless Steel

Phone: +8618668962766
Whatsapp: +8618668962766
Email: sales@rollformingindustry.com
Get a quote

Hot Rolled Galvanized Slitting Machine Line for Stainless Steel Slitting

Product description:

The slitting line is also called slitting unit, slitting machine, slitting machine, and scissors. It cuts the metal coils into strips of various required widths, and then collects the strips into small rolls for the next process. It is a necessary equipment for precision cutting of transformers, motor industries and other metal strips.

It is composed of the following:
entry coil car→ uncoiler,→slitter,→scrap coiler,→tension unit,→recoiler

Product parameter

Model/ Items	Thickness (mm)	Width (mm)	Slitting Number	Slitting Speed m/min	Coil Weight (ton)
RSL-0.5x1000	0.15-0.5	300-1000	12	50-150	7
RSL-0.5x1300	0.15-0.5	500-1300	24	50-150	7
RSL-2X650	0.3-2	200-650	10-30	50-150	7
RSL-2X1000	0.3-2	300-1000	10-30	50-150	7/15
RSL-2x1300	0.3-2	500-1300	12-30	50-180	7/15
RSL-2x1600	0.3-2	500-1600	12-30	50-180	7/15
RSL-3x1600	0.3-3	500-1600	8-30	50-180	15
RSL-3x1800	0.3-3	900-1800	8-30	50-180	20
RSL-4x1600	1-4	900-1600	6-30	50-120	20
RSL-6x1600	1-6	900-1600	6-30	30-80	30
RSL-10x2000	2-10	900-2000	5-30	30-50	30
RSL-12x2000	3-12	900-2000	5-30	20-40	30
RSL-16x2000	3-16	900-2000	5-30	20-40	40

Technical Strength:
1. We have an experienced expert with young active technical team, which can provide the professional with improved design solutions for our customers , assure that can satisfy various customer's special requirement by cost-effective way.

2. Our engineer always keep on design advanced , humane and most economic resolution for our customers, considering customers long time machine life, low cost maintenance and easy operation, save the cost of labor, maintenance, training for users. At same time, much higher efficiency

Our slitting machine carries out slitting on cold or hot rolling carbon steel, tinplates, stainless steel, and other kinds of metal that have coated surfaces. It is a useful slitting machine, widely used during the processing of home appliances, automobiles, hardware, steel products and more.
