Raintech Automatic Stainless Steel Pipe Making Machine ERW Tube Mill Machine
Product Description

PROCESSING OBJECTS AND REQUIREMENTS
Purpose: The equipment is mainly used for polishing the outside surface of the stainless steel
The workpiece range requirements:
1.Workpiece diameter range:19-76mm
2.Workpiece length range:6000mm

3.Final surface roughness:Ra 0.1 (Through surface friction many times)
4.Final finish requirements: Grinding and polishing
EQUIPMENT MAIN STRUCTURE AND PROPERITIES

The equipment mainly consists of one set of grinding head, a set of planetaryrotation system, a set of electrical control, a set of feeding system, a set of workpiece
receiving (releasing) mechanism, a set of dust removal system (optional).
1.Grinding head:
The machine is equipped with one set of grinding heads that can be used to polish the outside surface of the workpiece .According to the grinding

characteristics of the workpiece, use the abrasive belts as the grinding material. The grinding head consists of one polishing head motor, a support mechanism, a power drive mechanism, and a mounting plate.
2.Planetary rotation system:
The main function of this mechanism is to provide the required rotating motion of the grinding head during polishing. Motor power is

transmitted to the turnable through the V-belt to directly drive the turntable to rotate.It consists of a motor, turnable and a transmission device.
3.Electrical control:
The system's role is to input instructions, control of the machine movement to achieve control, mainly by the console and the electronic

control cabinet, inverter and various low-voltage electrical components.

4.Feeding system:
Feeding system is used for automatic feeding of straight tube polishing.It consists of roller, feeder ,backlash adjusting screw and motor drive

system.
5.Workpiece receiving (releasing) mechanism:
This is for supporting workpieces during straight tube polishing.It consists of adjusting screw, rubber wheels and pallet.

6.Dust removal system (optional):
The role of this system is to collect the dust generated during the grinding process, to solve the dust collection, easy maintenance

and cleaning. It is mainly composed of a cyclone dust collector, a bag vacuum cleaner, and dust collection pipes.

TECHNICAL PARAMETERS
Main technical performance parameters of the machine:
No Project Reachability Indicators
1 Effectively polished diameter(mm) 19-76mm
2 Effectively polished length (mm) 6000
3 Final surface roughness Ra 0.1(Through surface friction many times)
4 Dust emission treatment Meet national standards (optional)

Work environment requirements:
1 working environment temperature 0-60ºC
2 Relative humidity <90%
3 power supply voltage AC three-phase 380V
4 Power Frequency 50HZ
5 input power <10KW

Model List
